6X33mm Auto Replacement Parts For BMW M57 Swirl Blanks Flaps Repair Delete Kit With Intake Gaskets Key Blanks BX101567

6 X 33mm for BMW M57 Swirl Blanks Flaps Repair Delete Kit with Intake Gaskets

Information:
    Swirl flap substitute of the suction manifold (33 mm) with Viton O-rings- 6 pcs.
    material resistant to oil derivatives, as well as high and low temperatures
    Swirl flap substitute made of the PA66 GF35 material
    (the same material as in the case of suction manifold and swirl valves)
    Lack of differences in the thermal expansion between the plugs and the manifold
    O-RING VITON

Descriptions:
6 x 33 mm BMW swirl flap replacement with manifold gaskets

Swirl flaps substitute made of the PA66 GF35 material
They are made of the same material as swirl flaps and suction manifold

PA66 polyamide is a range of modified variants of construction materials in the form of granulated product, intended for the manufacture of products using the injection method. The variants reinforced in 35% with fiberglass (GF35) are intended for the manufacture of products with increased mechanical resistance and stiffness, especially in the automotive industry for the manufacture of machine parts.
The use of material causes the lack of heat accumulation phenomenon and differences in thermal expansion between the suction manifold and plugs- as is in the case of aluminum plugs.
*High thermal resistance, mechanical resistance and stiffness

O-Rings on VITON plugs
Operating temperature range: from-25 to 230 degrees of Celsius

Thanks to fluorine content, viton sealings are characterized by non-flammability. They are distinguished by thermal and chemical resistance.

Operating temperature range of viton sealings: from -25 to 200 degrees of Celsius, while short-term viton sealings can withstand a temperature up to 230 degrees of Celsius.

iton-based sealings (FKM-fluorocarbon rubber) are characterized by dimensional stability and have self-lubricating properties. The sealings made of fluorocarbon rubber are most commonly used in the automotive industry, including in engines and fuel systems.

Compability:
M57 / M57D25 (since 2000) 122 kW (164 HP), 350 Nm
    E39 525d (2000-2003) only for cars with automatic gearbox
M57N / M57TU / M57TUD25 (since 2004) 177 HP (130 kW; 175 HP), 400 Nm
    E60 / E61 525d
M57 / M57D30 (since 1998) 184 HP (135 kW; 181 HP), 390 Nm
    E39 530d only for cars with automatic gearbox
    E46 330d / 330xd only for cars with automatic gearbox
M57 / M57D30 (since 1998) 184 HP (135 kW; 181 HP), 410 Nm
    E38 730d only for cars with automatic gearbox
    E53 X5 3.0d
M57 / M57D30 (since 1998) 193 HP (142 kW; 190 HP), 410 Nm
    E38 730d
    E39 530d
M57N / M57TU / M57TUD30 (since 2002) 204 HP (150 kW; 201 HP), 410 Nm
    E46 330d / 330Cd / 330xd
    E83 X3 3.0d
M57N / M57TU / M57TUD30 (since 2002) 218 HP (160 kW; 215 HP), 500 Nm
    E53 X5 3.0d
    E60 / E61 530d / 530xd
    E65 730d
M57N / M57TU / M57TUD30 (since 2002) 272 HP (200 kW; 268 HP), 560 Nm
    E60 / E61 535d
M57N / M57TU / M57TUD30 (since 2002) 231 HP (170 kW; 228 HP), 500 Nm
    E90 / E90LCI / E91 / E91LCI / E92 / E93 335d
M57N / M57TU / M57TUD30 (since 2002) 286 HP (210 kW; 282 HP), 580 Nm
    E90 / E90LCI / E91 / E91LCI / E92 / E93 335d
M57TU2D30 (since 2007) 197 HP (145 kW; 194 HP), 400 Nm
    E90 / E91 / E92 325d
    E60 / E61 525d / 525xd
M57TU2D30 (since 2007) 231 HP (170 kW; 228 HP), 500 Nm
    E65 730d
    E90 / E91 325d
    E90 / E91 330d / 330xd
M57TU2D30 (since 2007) 235 HP (173 kW; 232 HP), 500 Nm
    E60 / E61 / E70 / E71
M57TU2D30 (since 2007) 286 HP (210 kW; 282 HP), 580 Nm
    E60 / E61 535d
    E70 X5 3.0sd
    E71 X6 xDrive35d
    E83 X3 3.0sd
    E90 / E91 335d
 Between 2004 and the beginning of 2005, two types of swirl valves were installed in 6-cylinder engines; please check before you buy.

Specifications:
Material: PA66 GF35
Size: 140 x 90 x 35mm/5.51 x 3.54 x 1.38″
Weight: 210g
DEDICATED: for 6-Cylinder-Diesel engines for BMW M57
Product code: AT-KZK-T33/6

The set includes:
6 x 33 mm Swirl Flap blanks (with O-Ring Viton, resistant to engine oils, and high and low temperature)
1 x Item No. 4  (Manifold gasket between the AGR valve and the intake manifold)
6 x Item No. 3 (Intake manifold gaskets upper against the cylinder head cover)
6 x Item No. 2 (Intake manifold gaskets lower against the cylinder head)

Packages:
1 x Set of Swirl Blanks Flaps Repair Delete Kit
