Product description
FD099 is a 433MHz RF PIR motion sensor that for human detection. The motion detector can work with the RF Bridge 433（Not included), providing human detected alarm message push to your phone.
Specification for PIR sensor
433MHz Transmit distance: 150m (open)
Voltage: 3V (2*AAA)
Battery type: 2*AAA (not included)
Standby current: ≤9μA
Alarm current: ≤10mA
Wireless frequency: 433.92MHz
Wireless Transmit Code: 1527Mhz (default)
Detection distance: 12m@ 25℃
Detection angle: 110 degrees
Maximum coverage area: 12m*12m
Alarm indicator light: on for 3 seconds
Working environment: indoor
Tamper switch: normally closed
Anti-white light intensity: 10000Lux
Product Size: 120*62*46mm
Weight: 120g
Package
Package Size: Approx. 16.5 * 6.5 * 5.0cm / 6.5 * 2.55 *1.97in
Package Weight: Approx. 91g / 3.2oz
