> All Dahua products sold in the store are 100% Dahua original
> This model Firmware cannot be upgraded, firmware cannot be upgraded, firmware cannot be upgraded!!!
> Firmware LanguageEnglish, Italian, Spanish, Russian, French, German, Polish, Portuguese. Korean, Persian, Czech, Dutch, Arabic，
> The product is not activated. When you receive the order, please log in to 192.168.1.108 to activate the camera.
>If the order sent to Europe exceeds 150 euros, the price does not include customs duties!!!When you receive the package, you need to pay customs duties.
>If you need a lot of cameras, you can contact our customer service and we will provide faster delivery methods (DHL, UPS, FEDEX) and offer you more discounts
Firmware Language
| Camera | |
| Image Sensor | 1/2.9” 6Megapixel progressive scan CMOS |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual, 1/3~1/100000s |
| Minimum Illumination | 0.002Lux(Color) |
| 0Lux(IR on) | |
| S/N Ratio | More than 56dB |
| IR Distance | Distance up to 50m |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 1 |
| Lens | |
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 2.8mm(3.6mm,6mm optional) |
| Max. Aperture | F2.5/F2.2/F2.0 |
| Angle of View | 2.8mm : H : 99° V : 69.4° 3.6mm : H : 70° V : 48° 6mm : H : 47.34° V : 33.75° |
| Optical Zoom | N/A |
| Focus Control | Fixed |
| Pan/Tilt/Rotation | |
| Pan/Tilt/Rotation Range | Pan:0˚~360˚; Tilt:0˚~78˚; Rotation:0˚~360˚ |
| Intelligence | |
| IVS | Tripwire, Intrusion, Object Abandoned/Missing |
| Video | |
| Compression | H.265+/H.265/H.264+/H.264 |
| Resolution | 6M(3072×2048)/ 5M(3072×1728)/ 5M(2592×1944)/ 4M(2688×1520)/ 3M(2048×1536)/ 3M(2304×1296)/ 1080P(1920×1080)/ 1.3M(1280×960)/ 720P(1280×720)/ D1(704×576/704×480)/ |
| / CIF(352×288/352×240) | |
| Frame Rate | 50Hz:Main Stream(3072×2048@20fps),Sub Stream(704×576@20fps),Third Stream(1280×720@6fps);Main Stream(2592×1944@25fps),Sub Stream(704×576@25fps),Third Stream(1280×720@4fps) |
| 60Hz:Main Stream(3072×2048@20fps),Sub Stream(704×480@20fps),Third Stream(1280×720@7fps);Main Stream2688×1520@30fps),Sub Stream(704×480@30fps),Third Stream(1280×720@10fps) | |
| Bit Rate | H.264: 24K ~ 10240Kbps H.265: 8K ~ 8192Kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detetion | Off / On (4 Zone, Rectangle) |
| Region of Interest | Off / On (4 Zone) |
| Electronic Image Stabilization (EIS) | N/A |
| Smart IR | Support |
| Defog | Support |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| Audio | |
| Compression | G.711a/ G.711Mu/ AAC/ G.726 |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP |
| Interoperability | ONVIF, PSIA, CGI |
| Streaming Method | Unicast / Multicast |
| Max User Access | 10 Users /20 Users |
| Edge Storage | NAS |
| Local PC for instant recording | |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS, Easy4ip |
| Smart Phone | IOS, Android |
| Interface | |
| Video Interface | N/A |
| Audio Interface | 1/1 channel In/Out RCA Build in Mic |
| Alarm | N/A |
| Electrical | |
| Power Supply | DC12V, PoE(802.3af)(Class 0) |
| Power Consumption | 3.08W,<4.8W |
| Environmental | |
| Operating Conditions | -40° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Strorage Conditions | -40° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | IK10 |
| Construction | |
| Casing | Metal |
| Dimensions | Φ106mm×94mm |
| Net Weight | 0.47kg |
| Gross Weight | 0.65kg |
