NOTE：This is AHD Camera , AHD Camera must use AHD DVR to make it working ! Don't support Analog DVR /NVR, it cann't directly connect to the TV/LCD monitor,please take notice !!!
AHD Camera Description
1. AHD 1080P,5MP
2. 3.6mm HD lens optional
3. Color CMOS Sensor, ICR
4. Metal housing,bullet camera outdoor indoor use
5. 24pcs IR leds light , 5-25M Max IR distance
About the choice of plug
We will choose the corresponding plug according to your country. We have EU UK AU US
|
Model |
AHD 1080P,5MP |
|
Sensor |
CMOS sensor |
|
Minimum Illumination |
Color:0.01Lux,(F1.2,AGC ON),0Lux with IR |
|
Black & White:0.001Lux,(F1.2,AGC ON),0Lux with IR |
|
|
Photosensitive Resistance |
1 photosensitive resistance interface, support the photosensitive resistor input signal and image, IR-CUT, infrared lamp linkage |
|
Shutter |
1/50(1/60) seconds to 1/10,000 seconds |
|
Day and Night Function |
Support IR-CUT |
|
Infrared light |
24pcs IR Leds |
|
Lens |
3.6mm |
|
Synchronous Mode |
inter-sync |
|
Noise-signal Ratio |
>58dB |
|
Temperature and Humidity |
– 10’C ~ 60’C, humidity is less than 90% (no condensation) |
|
Power |
DC12V±10% |
|
Consumption |
<5W |
|
Dimension |
17.6*6cm |
|
Housing material |
ABS plastic |
Packaging included:
2pcs AHD 1080P/5MP Cameras
1pcs 4CH AHD DVR
2pcs 20M BNC Cable
1pcs 12V/2A power adapter for dvr
1pcs 12V/2A power adapter for camera
1pcs 1-to-2 power splitter
1pcs mouse
some screws
Why choose us
Simicam uses real 1080p DVR, supports up to 5MP,
and the camera uses metal shell, which has better waterproof performance and longer service life
High Quality Night Vision Smart Infrared Cut Filter (ICR)
Camera has a very good night image quality. Infrared Cut Filter to ensure the highest quality images – day and night. During the day, the infrared cut filter drops in front of the lens to block the infrared lights from entering. This ensures that they do not affect the colors of the footage. When lighting levels become too low, this filter is automatically disengaged to allow the infrared light into the lens of the camera. This is when the full-color image turns to a monochrome black and white.
Locate incident Video with Smart Playback
The NVR Support H.265 video compression technology,better video quality&lessstorage
Motion Detection & Alarm Alert
Support ONVF 2.0
4CH DVR
