Technical Parameters
Voltage (V) DC 6/12/24V
No-load speed (mm/s) 4 8 15 30 150
Load push capacity (N) 150 70 50 20 7
Load pull capacity (N) 150 70 50 20 7
Statoc damping (N) 150 70 50 20 7
Stroke length (mm) 10mm,15mm,30mm,50mm,75mm,100mm,150mm,200mm
Operating temperature o~40℃
Limit switch Built-in
Operating frequency 10%
Inner tube Aluminum tube
Color Silver gray
Lead screw type T type
✦Advantage:Our Linear Actuator with Linear Reciprocating Motor and Durable Stroke Ideal for Intelligent Range Hood, Fan Blades, Cabinets, Window Opener, Robotics, Home Automation.
✦Feel Stop: Stop at Any Position,With Automatic Machine Lock, It will Automatically Stop When It Reaches the Top.
✦Safe and Worry-Free: Overcurrent Protection, Short Circuit Protection, Overload Protection, Overvoltage Protection.
✦1 Year product warranty,any problems about the product please feel free to contact us.
How to order
Drawing About Stroke Length (mm)
Please check below dimension drawing of IP60 Series linear actuator.
200 mm stroke
Min L=257.5mm
Max L=457.5mm
L(mm) means installation size/initial length, S(mm) means stroke length.
L=S+57.5mm
For example, when s (stroke length)=30mm, than L (installation size) will be equal to 87.5mm.
the length after telescopic rod comes out = L+S =117.5mm
Why Us?
● Over years we’ve been running, we have much experience in this field, provide customers with high quality and reliable goods.
● Our lab is equipped with professional inspection machines, every product will be strictly inspected and undergone a series of tests according to canonical operation specification and standard before delivery.
● OEM & ODM service are available.
● For bulk orders, we supply discount, and can ship goods via other delivery method, as air cargo or sea transportation.
● We accept paypal, western union, T/T and etc.
● Goods can be shipped within 1-4 days, delivery time depends on product series and quantity.
Warranty
● If you do not receive goods, please contact us, we will refund or send you a new one.
● If any damage by express company, please contact us at the first time you receive, we will refund or send you a new one.
● If any question about installation or using, just contact us freely, our sales and engineer are always available.
● When you place an order, please double check the delivery address, contact infomation and your name to make sure you can receive the goods.
If any question or need, you can directly leave message or send emails to ca****@*********nd.com or call us at +86 15726882369
Thanks for your insterest!
